纽荷兰零件查询(FD14E) - CRAWLER DOZER (93.4810[007A]) - DUAL TILT CYLINDER PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
542 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 14457180 | [2] | O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro | TTF0-RING -113, 70 Duro, .549" ID x .103" Thk Superseded by part number: 5146468 |
| 2. | 76011720 | [2] | HYD CONNECTOR | LECCONNECTOR |
| 3. | 73299686 | [2] | FLEXIBLE HOSE | NHHOSE Superseded by part number: REFERENCE |
| 4. | 70912441 | [2] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 80679 |
| 5. | 70921175 | [2] | BOLT | LECCAPSCREW,1/2""NC X 1"" Superseded by part number: 9790143 |
| 6. | 73157290 | [1] | RIGID TUBE | NHTUBE |
| 7. | 4982514 | [6] | CABLE TIE | LECTIE Superseded by part number: 87615202 |
| 8. | 79041613 | [2] | HOSE | LEC |
| 9. | 70927661 | [2] | ELBOW | CMI.900 Superseded by part number: 86513533 |
| 10. | 70917351 | [2] | BUSHING | CMI |
| 11. | 73600290 | [2] | PLUG | NHBUSHING |
