纽荷兰零件查询(FD14E) - CRAWLER DOZER (0.1550[004]) - AIR PRECLEANER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
408 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73153925 | [1] | AIR PRE-CLEANER ASSY | NHPRECLEANER |
| 2. | 73154057 | [1] | MESH | NHSCREEN |
| 3. | 73153924 | [1] | RIGID TUBE | NHTUBE |
| 4. | 70921916 | [1] | COLLAR | CMICLAMP Superseded by part number: 13001290 |
| 5. | 79042093 | [1] | GUARD | LECSLEEVE |
| 6. | 73043736 | [1] | CLAMP | CMI |
| 6. | 70922286 | [1] | SCREW | CMICAPSCREW,5/16""NCX2"" Superseded by part number: 281034 |
| 6. | 70677008 | [2] | WASHER | CMI |
| 6. | 70933622 | [1] | NUT | CMI5/16""NC |
| 7. | 73156442 | [1] | SUPPORT | NH |
| 7. | 16043634 | [4] | SCREW,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd | LECBOLT, Hex, M8 x 25, 10.9, Full Thd Superseded by part number: 16043637 |
| 7. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
