纽荷兰零件查询(FD14E) - CRAWLER DOZER (6.7010[004]) - STARTING RECEPTACLE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
787 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73144555 | [1] | CAP | CMI |
| 2. | 79096826 | [1] | POWER SOCKET | LECRECEPTACLE Superseded by part number: 76027602 |
| 2. | 10902631 | [4] | BOLT,Hex, M6 x 25mm, Cl 10.9 | BHB Superseded by part number: 10902633 |
| 2. | 14496431 | [8] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 2. | 12645031 | [4] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 2. | 15896221 | [4] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 3. | 79090112 | [1] | CAPPING | LECHOLDDOWN |
| 4. | 79090097 | [4] | TIE-ROD | LECSCREW |
| 4. | 16018779 | [4] | WASHER | NH |
| 4. | 79005244 | [4] | WASHER,10.6mm ID x 25mm OD x 6mm Thk | LEC |
| 5. | 79090096 | [1] | PLATE | LEC |
| 6. | 45011273 | [2] | ELECTRIC CABLE | TORCABLE, ELECTRIC |
| 7. | 79090094 | [1] | ELECTRIC CABLE | LECCABLE, ELECTRIC |
| 8. | 79090095 | [1] | ELECTRIC CABLE | LECCABLE, ELECTRIC |
