| 1. |
700123293
|
[3] |
WASHER
|
CAS
|
| 2. |
69260
|
[4] |
SET SCREW,Sq Hd, 1/2"-13 x 1"
|
CAS
1/2-13 X 1 CPSQHSS Superseded by part number: 85-816
|
| 3. |
700710414
|
[4] |
JAM NUT
|
CAS
1/2-13 HJN GR2
|
| 4. |
52316
|
[6] |
WASHER
|
CAS
1 X 10 GAUGE NRMB Superseded by part number: 495-81070, 495-81070, NLS
|
| 5. |
77057
|
[2] |
|
IH
1/4-28 X 90 DEGREE ZERK Superseded by part number: 87415, 87415, NLS
|
| 6. |
700123271
|
[2] |
ARM
|
CAS
ASM. - CAM (Includes Item 27)
|
| 7. |
52258
|
[2] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 8. |
62786
|
[2] |
RIVET,Rd Hd, M4 x 48, Aluminum
|
CAS
1/4 X 2-1/2 COTTER PIN Superseded by part number: 80752
|
| 9. |
704692
|
[2] |
NUT
|
CAS
1-14 SHN GR2 Superseded by part number: 86020752
|
| 10. |
702035
|
[6] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| 11. |
231-4116
|
[6] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 12. |
761312
|
[1] |
KEY
|
CAS
5/16 X 5/16 X 2-1/2 KEY
|
| 13. |
7852767
|
[4] |
RING
|
CAS
- RETAINING
|
| 14. |
700123291
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET ASM, (Includes Items 23)
|
| 15. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 16. |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 17. |
704734
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 18. |
700123263
|
[1] |
FINGER
|
CAS
|
| 19. |
700123266
|
[1] |
FINGER
|
CAS
WA - STUFFER
|
| 20. |
8746042
|
[2] |
LUBE NIPPLE
|
CAS
1/8-27 NPT X 5-1/2 NIPPLE
|
| 21. |
217-1050
|
[2] |
90 ELBOW,1/8" - 27 NPTF Female
|
CAS
1/8-27 NPT X 90 DEGREE PIPE ELBOW,BUSHING - reducer
|
| 22. |
77065
|
[2] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
CAS
1/8-27 ZERK Superseded by part number: 80710
|
| 23. |
700123304
|
[6] |
BRONZE BUSHING
|
CAS
BUSHING - BRONZE
|
| 24. |
700123292
|
[1] |
SHAFT
|
CAS
- STUFFER
|
| 25. |
700123287
|
[2] |
SUPPORT
|
CAS
ASM. (Includes Items 23)
|
| 26. |
700123298
|
[1] |
CRANK
|
CAS
WA - RIGHT
|
| 27. |
D22200
|
[2] |
BEARING,25.4mm ID x 36.5mm OD x 22.23mm L
|
CAS
BUSHING Superseded by part number: 87659928
|
| 28. |
6201404
|
[1] |
KEY
|
CAS
5/16 X 5/16 X 3-3/4 KEY
|
| 29. |
69203
|
[2] |
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
|
CAS
3/8-16 X 3/4 CPSQHSS Superseded by part number: 87616
|
| 30. |
7701188
|
[6] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 C Superseded by part number: 87670
|
| 31. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 32. |
86516876
|
[6] |
1/2-13 H
|
COVER
|
| 33. |
700706194
|
[2] |
NUT,3/4"-16, G8
|
CAS
3/4-16 H GR8 NP Superseded by part number: 29-1112
|
| 34. |
700710526
|
[2] |
CAMSHAFT BEARING,19.075 mm ID x 44.45 mm OD x 25.4, 44.45 mm
|
CAS
BEARING - CAM FOLLOWER (3/4 INCH THREAD) Superseded by part number: H748244
|
| 34. |
700711707
|
[2] |
CAM
|
CAS
BEARING - CAM FOLLOWER (1 INCH FINE THREAD)
|
| 35. |
77206
|
[2] |
FITTING
|
CAS
ZERK - DRIVE TYPE Superseded by part number: 80722
|
