凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (5-08) - CRANK DRIVE AND MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
488 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
50583
|
[2] |
FLANGED BEARING
|
IH
- BEARING Superseded by part number: 86979948
|
| 2. |
51318
|
[1] |
BEARING
|
IH
- SPHERICAL Superseded by part number: 668718R92, 47577169
|
| 3. |
68619
|
[8] |
BOLT,Round, 1/2" - 13 x 1 1/4", Grade 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 4. |
80679
|
[8] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
704031
|
[8] |
NUT
|
NNA
1/2-13 H Superseded by part number: 425-108, 425-108, NLS
|
| 6. |
413-1036
|
[4] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 7. |
7774482
|
[4] |
NUT
|
CAS
5/8-11 HTLN GR/C Superseded by part number: 85700693
|
| 8. |
8050601
|
[2] |
BEARING, ROLLER, CYL,15.875 mm ID x 49.213 mm OD x 20.65 mm
|
CAS
- CYLINDERICAL Superseded by part number: 617617R91
|
| 9. |
700121909
|
[2] |
LINK CONROD
|
CAS
LINK ASSEMBLY (Includes Item 8) Superseded by part number: 700124038, 700124036
|
| 10. |
52548
|
[6] |
SPECIAL WASHER
|
CAS
2 X 14 GAUGE NRMB
|
| 11. |
714360
|
[2] |
FLANGED BEARING
|
IH
FLANGE - BEARING
|
| 12. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - SPHERICAL Superseded by part number: 47577203
|
| 13. |
740407
|
[2] |
BRUSH, COMMUTATOR
|
CAS
2 X 10 GAUGE NRMB
|
| 14. |
700123418
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 80C35
|
| 15. |
700113661
|
[1] |
NUT
|
CAS
1-5/8-12 STAKE NUT
|
| 16. |
700113666
|
[1] |
SPACER
|
CAS
|
