凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-10) - KNOTTER HEAD ASSEMBLY, CONTINUED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700700969
|
[1] |
BILL HOOK
|
CAS
ASSEMBLY Superseded by part number: 700734489
|
| 2. |
37-138
|
[1] |
DOWEL,3/16" x 1/2"
|
CAS
3/16 X 1/2 DOWEL PIN Superseded by part number: 88251
|
| 3. |
1712835
|
[1] |
HOOK
|
CAS
TONGUE - BILL HOOK Superseded by part number: 700734488
|
| 4. |
8701625
|
[2] |
SCREW,Hex, #10 - 32 x 1/2"
|
CAS
#10-32 X 1/2 HHMS GRD 2 Superseded by part number: 86637658
|
| 5. |
700102136
|
[1] |
KNIFE
|
CAS
BASE - KNIFE, TWINE
|
| 6. |
49783
|
[1] |
KNIFE
|
CAS
- TWINE Superseded by part number: 700718710
|
| 7. |
6613624
|
[1] |
WASHER, LOCK
|
CAS
TAB - LOCK
|
| 8. |
704148
|
[1] |
NUT
|
CAS
1/2-20 H Superseded by part number: 280963
|
| 9. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 10. |
6591572
|
[1] |
WASHER
|
CAS
- SPECIAL Superseded by part number: 87364
|
| 11. |
7852593
|
[2] |
SHIM,15mm ID x 21mm OD x 1mm Thk
|
CAS
MACHINERY BUSHING - SPECIAL Superseded by part number: 84007145
|
| 12. |
700122799
|
[1] |
ROLLER
|
CAS
- SPHERICAL
|
| 13. |
7852577
|
[1] |
RING, SNAP
|
CAS
RING - RETAINER
|
| 14. |
6591580
|
[1] |
SHAFT
|
CAS
- STRIPPER ARM
|
| 15. |
733048
|
[1] |
O-RING
|
CAS
Superseded by part number: 128359
|
