凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-14) - KNOTTER BRAKE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7770506
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 X 3-1/2 RHSNB Superseded by part number: 280348
|
| 2. |
700709603
|
[6] |
WASHER,3/8"
|
CAS
3/8 WIDE PLAIN WASHER Superseded by part number: 80702
|
| 3. |
74781
|
[6] |
NUT
|
CAS
3/8-16 LHSN Superseded by part number: 231-1406, 231-1406, NS
|
| 4. |
69252
|
[1] |
SET SCREW
|
CAS
1/2-13 X 3/4 CPSQHSS Superseded by part number: 86624113
|
| 5. |
700123384
|
[1] |
ARM
|
CAS
WA - RIGHT
|
| 6. |
69260
|
[1] |
SET SCREW,Sq Hd, 1/2"-13 x 1"
|
CAS
1/2-13 X 1 CPSQHSS Superseded by part number: 85-816
|
| 7. |
61879
|
[1] |
KEY
|
CAS
|
| 8. |
6561351
|
[1] |
CAP WASHER
|
CAS
|
| 9. |
7701949
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
5/8-11 X 2 C Superseded by part number: 86505999
|
| 10. |
705061
|
[1] |
PLUG
|
NNA
5/8" Superseded by part number: 492-11062
|
| 11. |
6553275
|
[9] |
SHIM
|
CAS
- COUNTERSHAFT
|
| 12. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8 P Superseded by part number: 87613283
|
| 13. |
58644
|
[6] |
SPRING
|
CAS
- COMPRESSION
|
| 14. |
6578868
|
[2] |
LARGE PLATE
|
CAS
PLATE - PRESSURE
|
| 15. |
700710945
|
[2] |
CLUTCH PLATE,126.75mm ID x 203.2mm OD x 3.18mm Thk
|
L
DISC - CLUTCH
|
