凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-28) - TENSION ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
914 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
771345
|
[1] |
SCREW,Hex, #10 - 24 x 1"
|
CAS
#10-24 X 1 HWHMS Superseded by part number: 363-31016
|
| 2. |
705004
|
[1] |
LOCK WASHER
|
CAS
#10 L Superseded by part number: 80684
|
| 3. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
10-24 H GR2
|
| 4. |
6578751
|
[1] |
ARM
|
CAS
WA - TENSION
|
| 5. |
9967191
|
[1] |
PIN
|
COE
1/4 X 1 CLP
|
| 6. |
89987
|
[1] |
CHAIN (AG)
|
HFI
LINK - CHAIN
|
| 7. |
705707
|
[1] |
WASHER,1/4", SAE
|
CAS
1/4 NARROW PLAIN WASHER Superseded by part number: 87361
|
| 8. |
62018
|
[1] |
PIN
|
CAS
1/16 X 1/2 COTTER PIN Superseded by part number: 280236
|
| 9. |
62117
|
[1] |
PIN
|
CAS
1/8 X 1-1/4 COTTER PIN Superseded by part number: 87395
|
| 10. |
7849656
|
[1] |
SLEEVE
|
CAS
- ROLLER
|
| 11. |
6529945
|
[1] |
ROLLER
|
CAS
- NEEDLE
|
| 12. |
7849110
|
[1] |
BUSHING,5.23mm ID x 6.99mm OD x 13.49mm L
|
CAS
BUSHING - ROLLER
|
