凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-26) - TENSIONER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
441 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
8071781
|
[2] |
1/2 X 1-1/2 X 3/8 -16 HSHSS (Special) ( replaced 8071781 )
|
|
| 2. |
7703473
|
[2] |
BOLT,Hex, 1/4" - 20 x 1 1/4", Gr 5
|
CAS
1/4-20 X 1-1/4 C Superseded by part number: 87716
|
| 3. |
704007
|
[2] |
NUT,1/4"-20, G5
|
CAS
1/4-20 H Superseded by part number: 7770
|
| 4. |
700709601
|
[2] |
WASHER,1/4"
|
CAS
1/4 WIDE PLAIN WASHER Superseded by part number: 80701
|
| 5. |
7770571
|
[2] |
BOLT,Square, 3/8" - 16 x 6"
|
CAS
3/8-16 X 6 RHSNB - SPECIAL
|
| 6. |
7704141
|
[2] |
EXTENSION
|
NNA
3/8-16 HTLN GR/B Superseded by part number: 231-4116
|
| 7. |
700709603
|
[2] |
WASHER,3/8"
|
CAS
3/8 WIDE PLAIN WASHER Superseded by part number: 80702
|
| 8. |
6845135
|
[1] |
PLATE
|
CAS
WA
|
| 9. |
704023
|
[2] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 10. |
705038
|
[2] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 11. |
6845101
|
[1] |
BRACKET
|
CAS
WA
|
| 12. |
858027
|
[2] |
COMPRESSION SPRING
|
CAS
SPRING - COMPRESSION
|
| 13. |
6530828
|
[2] |
SPACER
|
CAS
|
| 14. |
8802795
|
[2] |
GEAR
|
CAS
- TENSION
|
