| 1. |
700710360
|
[2] |
SHIM
|
HFI
-LEFT, 0.51 / .020
|
| 2. |
700710359
|
[1] |
SHIM
|
CAS
-LEFT, 0.25 / .010
|
| 3. |
700710358
|
[1] |
SHIM
|
CAS
-LEFT, 0.13 / .005
|
| 4. |
614-12025
|
[12] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 300388
|
| 5. |
700123102
|
[1] |
CAP
|
CAS
-LEFT
|
| 6. |
700710357
|
[2] |
SHIM
|
CAS
-LEFT, 0.08 / .003
|
| 7. |
700710353
|
[1] |
GEAR-SET
|
CAS
RING GEAR AND PINION
|
| 8. |
921684C1
|
[1] |
BEARING ASSY,2.9528" ID x 5.7087" OD x 2.0079"
|
IH
CONE-BEARING Superseded by part number: 924849C1
|
| 9. |
921683C1
|
[1] |
BEARING CUP,5.7087" OD x 1.6535"
|
IH
CUP-BEARING Superseded by part number: 924849C1
|
| 10. |
700710389
|
[2] |
SHIM
|
CAS
-PINION, INPUT 0.51 / .020
|
| 11. |
700710386
|
[2] |
SHIM
|
HFI
-PINION, INPUT 0.08 / .003
|
| 12. |
700710387
|
[1] |
SHIM
|
CAS
-PINION, INPUT 0.13 / .005
|
| 13. |
700710388
|
[1] |
SHIM
|
CAS
-PINION, INPUT 0.25 / .010
|
| 14. |
700710382
|
[2] |
SEAL
|
CAS
-OIL
|
| 15. |
614-10030
|
[6] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Hex, M10 x 30; 8.8 Superseded by part number: 43140
|
| 16. |
700708367
|
[6] |
WASHER
|
HFI
10 L Superseded by part number: 140028
|
| 17. |
700123101
|
[1] |
CAP
|
CAS
-FRONT
|
| 18. |
700710371
|
[1] |
GASKET
|
CAS
-FRONT CAP
|
| 19. |
700710410
|
[1] |
NUT
|
CAS
-STAKE
|
| 20. |
700710383
|
[1] |
WASHER
|
CAS
-SPECIAL
|
| 21. |
ST2175
|
[1] |
BEARING, CONE,79.25mm ID x 19.05mm W
|
IH
CONE-BEARING
|
| 22. |
700710378
|
[1] |
BEARING, CUP
|
CAS
CUP-BEARING
|
| 23. |
A50529
|
[1] |
BEARING CUP,147.03mm OD x 32.5mm W
|
CAS
CUP-BEARING
|
| 24. |
700710364
|
[1] |
SHIM
|
CAS
-RIGHT 0.51 / .020
|
| 25. |
700710362
|
[1] |
SHIM
|
CAS
-RIGHT 0.13 / .005
|
| 26. |
700701720
|
[1] |
SEAL
|
CAS
-OIL
|
| 27. |
700123103
|
[2] |
CAP
|
CAS
-RIGHT
|
| 28. |
700710361
|
[1] |
SHIM
|
CAS
-RIGHT 0.08 / .003
|
| 29. |
700710363
|
[1] |
SHIM
|
CAS
-RIGHT 0.25 / .010
|
| 30. |
A50532
|
[1] |
ROLLER BEARING,89.97mm ID x 40.2mm W
|
CAS
CONE-BEARING
|
| 31. |
700710352
|
[1] |
PINION
|
CAS
|
| 32. |
1-1357
|
[1] |
ROLLER BEARING,133.35mm ID x 39.69mm W
|
CAS
CONE-BEARING Superseded by part number: 47941920
|
| 33. |
1-1358
|
[1] |
BEARING CUP,190.5mm OD x 33.34mm W
|
CAS
CUP-BEARING Superseded by part number: 47941920
|
