凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (2-24) - AUXILIARY DRIVE ASSEMBLY, LEFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
789 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200277
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - IDLER
|
| 2. |
241-4418
|
[1] |
LINK
|
CAS
-CONNECTOR, #80 R/C Superseded by part number: 632415
|
| 3. |
654437R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN-ROLLER, #80 (10 FOOT BULK)
|
| 4. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 5. |
700123337
|
[1] |
SPECIAL BOLT
|
CAS
DRAW BOLT WA
|
| 6. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 7. |
326-1256
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 8
|
CAS
|
| 8. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 9. |
425-1012
|
[1] |
NUT,3/4"-10, G5
|
CAS
3/4-10 H Superseded by part number: 280954
|
| 10. |
52183
|
[2] |
BUSHING
|
CAS
3/4 X 18 GAUGE NRMB Superseded by part number: Z52183
|
| 11. |
95-81182
|
[1] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
3/4 X 14 GAUGE NRMB
|
| 12. |
700123122
|
[1] |
WASHER
|
CAS
- SPECIAL
|
| 13. |
700123335
|
[1] |
BUSHING
|
CAS
|
| 14. |
6579106
|
[1] |
LARGE PLATE
|
CAS
CAP - PLATE Superseded by part number: 706579106
|
| 15. |
413-12112
|
[1] |
BOLT,Hex, 3/4" - 10 x 7", Gr 5
|
CAS
3/4-10 X 7 C Superseded by part number: 280316
|
| 16. |
232-41112
|
[1] |
NUT,3/4"-10, GC
|
CAS
NUT, LOCK, 3/4"-10, GC Superseded by part number: 280375
|
| 17. |
413-8320
|
[6] |
1/2-13 X 2 C
|
|
| 18. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 19. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
