纽荷兰零件查询(FD14E) - CRAWLER DOZER (96.7560[001]) - DIAGNOSTIC SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
572 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 10181714 | [6] | BANJO BOLT | LECFITTING 12x1,5x11 Superseded by part number: 10181717 |
| 2. | 2854292 | [12] | SEALING WASHER,12mm ID x 17mm OD x 1.5mm Thk | TORWASHER, SEALING, , Copper M12.2 x 18 x 1.5 Superseded by part number: 10298460 |
| 3. | 79038298 | [6] | HYD CONNECTOR | LECFITTING |
| 4. | 79072548 | [4] | HYD CONNECTOR | LECFITTING |
| 5. | 79094617 | [1] | FLEXIBLE HOSE,1350.00 mm | LEC1350.00 mm |
| 6. | 79094618 | [1] | FLEXIBLE HOSE,8.00 mm ID x 1450.00 mm | LEC8.00 mm ID x 1450.00 mm |
| 7. | 79094619 | [1] | FLEXIBLE HOSE,1850.00 mm | LEC1850.00 mm |
| 8. | 79094620 | [1] | FLEXIBLE HOSE,1500.00 mm | LEC1500.00 mm |
| 9. | 79094621 | [1] | FLEXIBLE HOSE,1700.00 mm | LEC1700.00 mm |
| 10. | 79094693 | [1] | DECAL | LECC2663 Superseded by part number: 79096873 |
| 10. | 79096873 | [1] | DECAL | LECD2663 |
| 11. | 79096840 | [1] | FLEXIBLE HOSE | LECHOSE D2663 |
| 12. | 4982514 | [2] | CABLE TIE | LECCLAMP D2663 Superseded by part number: 87615202 |
