纽荷兰零件查询(FD14E) - CRAWLER DOZER (96.7130[001A]) - COLD WEATHER START New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
933 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79070430 | [1] | SWITCH | LEC |
| 2. | 73156423 | [1] | WIRE HARNESS | NHCABLE, ELECTRIC |
| 3. | 73156395 | [1] | WIRE HARNESS | NHCABLE, ELECTRIC |
| 4. | 73075165 | [1] | HYDRAULIC VALVE | CMIVALVE |
| 4. | 70928138 | [2] | SCREW | BHBCAPSCREW.1/4-NCX5/8"" |
| 4. | 70917730 | [2] | NUT | CMI1/4""NC |
| 5. | 73115566 | [1] | SPARE PART,0.063" ID, 0.25" OD, 48" Length | CMITUBE Superseded by part number: 73110484 |
| 5. | 73052086 | [1] | ELBOW | BHB Superseded by part number: 70917310 |
| 5. | 70911841 | [2] | CONE TYPE FERRULE | BHBSLEEVE |
| 5. | 70912589 | [2] | NUT | BHB |
| 6. | 73119442 | [1] | NOZZLE | CMIATOMIZER |
| 7. | 73153908 | [1] | WIRE HARNESS | NHCABLE, ELECTRIC |
| 8. | 73075166 | [1] | THERMOSTAT | CMITHERMOGUARD |
| 9. | 73138080 | [1] | PLATE | CMIBRACKET |
| 9. | 70921566 | [3] | SCREW | CMICAPSCREW,5/16""NCXr Superseded by part number: 280341 |
| 9. | 70904205 | [3] | LOCK WASHER | CMIWASHER Superseded by part number: 83990583 |
| 9. | 70677005 | [3] | WASHER,8.73mm ID x 19.05mm OD x 3.4mm Thk | CMILOCKWASHER |
| 9. | 70933622 | [3] | NUT | CMI5/16""NC |
| 10. | 70198775 | [10] | CLAMP | CMITIE Superseded by part number: 4982514 |
| 11. | 70669359 | [1] | BRACKET | BHBCLAMP |
| 12. | 73132158 | [1] | CYLINDER | CMI |
| 13. | 73070169 | [1] | GASKET | BHB |
