凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (8-08) - HYDRAULIC BALE DENSITY ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
356 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700711512
|
[2] |
CYLINDER
|
CAS
HYDRAULIC CYLINDER ASSEMBLY (Includes Ref: 10 and 11)
|
| 2. |
8799280
|
[2] |
FILTER
|
CAS
|
| 3. |
700713988
|
[1] |
TUBE
|
CAS
LINE-HYDRAULIC
|
| 4. |
121-115
|
[4] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 5. |
232-5315
|
[4] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 6. |
515-2363
|
[4] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
1/4 CLAMP Superseded by part number: 675162
|
| 7. |
700701355
|
[1] |
3 WAY CONNECTION
|
CAS
TEE Superseded by part number: 86513653
|
| 8. |
700710059
|
[2] |
HYDRAULIC HOSE,6.35 mm ID x 530.00 mm, SAE 100R7
|
CAS
6.35 mm ID x 530.00 mm, SAE 100R7
|
| 9. |
218-1054
|
[2] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 1/2"-14, NPTF
|
CAS
|
| 10. |
427-16350
|
[4] |
CLEVIS PIN,25.4mm OD x 88.9mm L
|
IH
1 X 3-1/2 CLEVIS PIN
|
| 11. |
S120261
|
[4] |
PIN
|
CAS
.148 WIRE HAIR PIN COTTER
|
