纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.042[01]) - ENGINE OIL SUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 99455178 | [1] | ENGINE OIL PAN | LEC |
| 2. | 98424115 | [1] | GASKET,0.8mm Thk | TOR |
| 3. | 10265060 | [1] | SEALING WASHER,32.4mm ID x 38mm OD x 1.5mm Thk | TOR |
| 4. | 16993611 | [1] | PLUG | COE32X1,5 |
| 5. | 10118811 | [1] | PLUG,M22 x 1.5 x 14, Cl5.8 | JES Superseded by part number: 221579A1 |
| 6. | 15970924 | [25] | SCREW,Hex, M10 x 1.25 x 35mm, Cl 8.8 | TTF Superseded by part number: 16204524 |
| 7. | 11288024 | [1] | BOLT,Hex, M10 x 1.25 x 60mm, Cl 8.8 | TTF |
| 8. | 15972424 | [2] | SCREW,Hex, M10 x 1.25 x 130mm, Cl 8.8 | JES Superseded by part number: 15972421 |
| 8. | 15888724 | [1] | BOLT,Hex, M10 x 1.25 x 55mm, Cl 8.8 | TTF |
| 9. | 15540724 | [3] | SCREW,Hex, M12 x 1.25 x 45mm, Cl 8.8 | TTF |
| 10. | 11190774 | [3] | BELLEVILLE WASHER,13.00mm ID x 24.00mm OD x 2.80mm, 3.30mm, Cl 8.8, DAC | TTF |
| 11. | 11190574 | [29] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 12. | 4763177 | [1] | PLUG | LEC |
| 13. | 14438089 | [1] | GASKET | LEC2,4X19,3 Superseded by part number: 14438085 |
| 14. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
