| 1. |
121-115
|
[16] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 2. |
231-5145
|
[24] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
700133095
|
[1] |
SHIELD
|
HFI
-FLYWHEEL
|
| 4. |
340-1108
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS GR 60M
|
| 5. |
195-513
|
[2] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 6. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 7. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 8. |
700714529
|
[1] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 9. |
700133084
|
[1] |
SUPPORT
|
HFI
-LATCH
|
| 10. |
700133097
|
[2] |
SUPPORT
|
HFI
-SHIELD
|
| 11. |
413-556
|
[4] |
BOLT,Hex, 5/16" - 18 x 3-1/2", Gr 5
|
CAS
5/16-18 X 3-1/2 Superseded by part number: 86507008
|
| 12. |
495-61034
|
[4] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 13. |
700133088
|
[1] |
SHIELD
|
HFI
WA-REAR
|
| 14. |
700709866
|
[1] |
WASHER
|
CAS
-WASHER, CAMLOC
|
| 15. |
CAS758342
|
[1] |
SPRING
|
CAS
-COMPRESSION
|
| 16. |
700133083
|
[2] |
SHIELD
|
HFI
|
| 17. |
121-3
|
[2] |
SERRATED BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
|
| 18. |
700133089
|
[1] |
SHIELD
|
HFI
|
| 19. |
700711134
|
[1] |
SCREW
|
CAS
3/8-16 X 1-3/4 HFS GR8
|
| 20. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 21. |
413-528
|
[2] |
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707515, 72187200
|
| 22. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 23. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 24. |
121-226
|
[6] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 25. |
700133094
|
[1] |
SHIELD
|
HFI
|
| 26. |
863381
|
[1] |
CLIP,9.53mm OD x 50.8mm L
|
CAS
3/8 X 2 CLEVIS PIN
|
| 27. |
700123830
|
[1] |
CHANNEL
|
CAS
-SUPPORT Superseded by part number: 700150655
|
| 28. |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 29. |
434-616
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 30. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 31. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 32. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 33. |
700123831
|
[1] |
SUPPORT
|
CAS
-STRAP
|
| 34. |
256873
|
[12] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 35. |
700113640
|
[1] |
SUPPORT
|
CAS
WA Superseded by part number: 700150657
|
| 36. |
700133085
|
[1] |
SHIELD
|
HFI
-FRONT
|
| 37. |
700133086
|
[1] |
SHIELD
|
HFI
WA-LOWER
|
| 38. |
700707203
|
[1] |
CAPTIVE WASHER SCREW
|
CAS
#12-24 X 3/4 HWHMS
|
| 39. |
1954816C1
|
[1] |
LOCK NUT
|
IH
#12-24 HCLN - SPECIAL Superseded by part number: 848083
|
| 40. |
700708648
|
[1] |
BUMPER
|
CAS
|
| 41. |
700133093
|
[1] |
SHIELD
|
HFI
-PTO Superseded by part number: 86637953, 700133195, 9707515, 700709866, CAS758342, 232-5315, 700137803
|
| 42. |
700133096
|
[1] |
SHIELD
|
HFI
|
| 43. |
65250
|
[1] |
PIN,4.76mm OD x 571.5mm L
|
CAS
-HINGE
|
| 44. |
700714528
|
[1] |
LATCH
|
CAS
-1/4 TURN Superseded by part number: 292505A1
|
| 45. |
700133091
|
[1] |
SHIELD
|
HFI
WA
|
