纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.140[03]) - INJECTION EQUIPMENT - REGULATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
991 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9969148 | [1] | COVER | LEC- ASSY |
| 2. | 9967945 | [4] | PLUG | ZED |
| 3. | 79097287 | [1] | SCREW | TOR |
| 4. | 79097288 | [1] | NUT | TOR |
| 5. | 9969149 | [1] | STUD | LEC |
| 6. | 71452918 | [1] | NUT | TOR |
| 7. | 9967228 | [1] | SCREW | TOR |
| 8. | 15896221 | [1] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 9. | 9967875 | [4] | SCREW | ZED6X25 |
| 10. | 9970295 | [1] | LEVER | TOR- ASSY |
| 11. | 79111846 | [1] | SCREW | TOR6X20 |
| 12. | 9967237 | [1] | GASKET | MOD |
| 13. | 9968655 | [1] | SCREW | TOR |
| 14. | 9969151 | [1] | PLUG | LEC |
| 15. | 9969155 | [2] | RETAINING PLATE | LEC |
| 16. | 9968661 | [4] | SCREW | TOR |
| 17. | 9967236 | [1] | CUP | TOR |
| 18. | 9969154 | [2] | BUSHING | LEC |
| 19. | 9968662 | [2] | SEAL | TOR |
| 20. | 9967418 | [1] | SEALING RING | ZED |
| 21. | 10205710 | [1] | WOODRUFF KEY,3mm x 5mm x 12.65mm | TTF |
| 22. | 9968670 | [2] | SCREW | TOR |
| 23. | 9969152 | [1] | SCREW | LEC- ASSY |
| 24. | 9967231 | [1] | SPRING | MOD |
| 25. | 9968659 | [1] | NUT | TOR |
| 26. | 79097270 | [1] | SEALING RING | TOR |
| 27. | 75207995 | [1] | COVER | TOR |
| 28. | 9969161 | [2] | SCREW | LEC |
