凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (5-08) - CRANK DRIVE AND MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
439 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
50583
|
[2] |
FLANGED BEARING
|
IH
-BEARING Superseded by part number: 86979948
|
| 2. |
668719R92
|
[1] |
BEARING ASSY,1.7505" ID x 3.346" OD x 1.1875" Thk
|
IH
BEARING-SPHERICAL Superseded by part number: 668718R92
|
| 3. |
433-820
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 4. |
80679
|
[8] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
425-108
|
[8] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 6. |
413-1036
|
[4] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 7. |
232-41110
|
[4] |
NUT,5/8"-11, GC
|
CAS
NUT, LOCK, 5/8"-11, GC Superseded by part number: 85700693
|
| 8. |
616154R92
|
[4] |
BEARING, ROLLER, CYL,16 mm
|
IH
BEARING-CYLINDRICAL Superseded by part number: 84356151
|
| 9. |
700124036
|
[2] |
LINK CONROD
|
CAS
LINK ASSEMBLY (Includes Ref: 8)
|
| 10. |
52548
|
[6] |
SPECIAL WASHER
|
CAS
2 X 14 GAUGE NRMB
|
| 11. |
714360
|
[2] |
FLANGED BEARING
|
IH
FLANGE-BEARING
|
| 12. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING-SPHERICAL Superseded by part number: 47577203
|
| 13. |
740407
|
[2] |
BRUSH, COMMUTATOR
|
CAS
2 X 10 GAUGE NRMB
|
| 14. |
700123418
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA-80C35 TOOTH
|
| 15. |
700113661
|
[1] |
NUT
|
CAS
1-5/8-12 STAKE NUT
|
| 16. |
700113666
|
[1] |
SPACER
|
CAS
|
| 17. |
700124038
|
[8] |
BUSHING,16.27mm ID x 34.92mm OD x 10mm L
|
CAS
-BEARING
|
