纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.140[09]) - INJECTION EQUIPMENT - CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
625 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 13421876 | [1] | CIRCLIP | BAS |
| 2. | 4766813 | [2] | BUSHING,49.98mm ID x 54.18mm OD x 30mm L | MOD |
| 3. | 4667498 | [1] | WASHER | FOR30 |
| 4. | 4852809 | [1] | ECCENTRIC | BRE |
| 5. | 4852812 | [1] | UNIVERSAL JOINT | TOR |
| 6. | 4708213 | [1] | RING | FOR |
| 7. | 98445184 | [1] | GEAR | BRE |
| 8. | 4853228 | [1] | SHAFT | BRE |
| 9. | 98415428 | [1] | SUPPORT | BRE- ASSY |
| 10. | 11190574 | [2] | BELLEVILLE WASHER,Belleville, M10.5 | TTF |
| 11. | 13449824 | [4] | STUD | MKT10X1,25X15X35 Superseded by part number: 13449830 |
| 12. | 14233624 | [4] | BOLT,Hex, M10 x 1.25 x 30mm, Cl 8.8, Full Thd | BAS |
| 13. | 16321624 | [6] | SCREW,M8 x 1.25 x 24mm | LEC8X1,25X24 |
| 14. | 99435566 | [1] | SEAL | TOR |
| 15. | 17285781 | [1] | SEAL | BRE2,62X94,92 |
| 16. | 14453581 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 7, 75 Duro | BAS Superseded by part number: 17278581 |
| 17. | 15970724 | [2] | SCREW,Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd | TTF |
| 18. | 4852808 | [1] | WASHER | BRE |
| 19. | 98415571 | [2] | WASHER | BRE |
| 20. | 98488133 | [1] | GASKET | BRE |
| 21. | 1900149 | [1] | KIT | NH Superseded by part number: 1940149 |
| 21. | 1940151 | [1] | ENGINE GASKET KIT | LEC |
