| 1. |
758441
|
[1] |
SPRING
|
IH
-EXTENSION
|
| 2. |
432-1016
|
[2] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 3. |
413-624
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 4. |
232-5316
|
[5] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
920091951
|
[6] |
BELLEVILLE WASHER
|
COE
-CONICAL
|
| 6. |
827360
|
[3] |
HANDLE
|
CAS
GRIP
|
| 7. |
700129689
|
[1] |
SUPPORT
|
CAS
-LEVER
|
| 8. |
700129686
|
[1] |
LEVER
|
CAS
ASM
|
| 9. |
700123852
|
[1] |
ARM
|
CAS
WA
|
| 10. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 11. |
6621825
|
[1] |
SPACER
|
CAS
BUSHING
|
| 12. |
700123860
|
[1] |
ROD
|
CAS
-STARWHEEL
|
| 13. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 14. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 15. |
066183
|
[1] |
CLEVIS
|
IH
Superseded by part number: 70937465
|
| 16. |
427-8150
|
[1] |
CLEVIS PIN,1/2" x 1 1/2"
|
CAS
1/2X1.500 1.281 HD/HOLE CLEVIS ZND
|
| 17. |
433-512
|
[4] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 18. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 19. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 20. |
111-505
|
[1] |
CARRIAGE BOLT,Short NK, 1/2"-13 x 3 1/2", G5
|
CAS
BOLT, CARRIAGE, Short NK, 1/2"-13 x 3 1/2", G5
|
| 22. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 23. |
111-360
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 24. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 25. |
492-11038
|
[5] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 26. |
425-106
|
[5] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 27. |
700123855
|
[1] |
SHAFT
|
CAS
-STARWHEEL
|
| 28. |
232-53110
|
[2] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 29. |
700133189
|
[1] |
SHIELD
|
CAS
WA-STARWHEEL Superseded by part number: 700153538
|
| 30. |
700123856
|
[1] |
SPROCKET ASSY.
|
CAS
STARWHEEL
|
| 31. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 32. |
256873
|
[4] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 33. |
700133188
|
[1] |
SHIELD
|
CAS
COVER-STARWHEEL
|
| 34. |
219-1
|
[2] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
1/8-27 ZERK Superseded by part number: 80710
|
| 35. |
6530265
|
[1] |
BRACKET
|
CAS
WA-STARWHEEL
|
| 36. |
433-640
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/2", Gr 5
|
CAS
3/8-16 X 2-1/2 RHSNB Superseded by part number: 280744
|
| 37. |
700123859
|
[1] |
SUPPORT
|
CAS
|
| 38. |
6229298
|
[1] |
SPACER
|
CAS
BUSHING
|
| 39. |
700123991
|
[1] |
LEVER
|
CAS
ASSEMBLY
|
| 40. |
700123850
|
[2] |
SHIELD
|
CAS
-WHEEL
|
| 41. |
700123857
|
[1] |
ARM
|
CAS
WA-TRIP Superseded by part number: 700161047
|
| 42. |
6530489
|
[1] |
HUB
|
CAS
SPACER
|
| 43. |
700109003
|
[1] |
BUSHING
|
CAS
|
| 44. |
413-644
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 2 3/4", G5 Superseded by part number: 88444
|
| 45. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
