凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (6-04) - TENSION ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
644 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
363-31016
|
[4] |
SCREW,Hex Wash Hd, #10-24 x 1"
|
CAS
#10-24 X 1 HWHMS
|
| 2. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 3. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 4. |
6523765
|
[4] |
ARM
|
CAS
-TENSION Superseded by part number: 700150609
|
| 5. |
413-520
|
[4] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 6. |
492-11031
|
[4] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 7. |
425-105
|
[4] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 8. |
6523799
|
[4] |
BUSHING
|
CAS
-TENSIONER
|
| 9. |
7849656
|
[4] |
SLEEVE
|
CAS
-ROLLER
|
| 10. |
6529945
|
[4] |
ROLLER
|
CAS
|
| 11. |
7849110
|
[4] |
BUSHING,5.23mm ID x 6.99mm OD x 13.49mm L
|
CAS
BUSHING-ROLLER
|
