| 1. |
700129451
|
[4] |
CHANNEL
|
CAS
guide
|
| 2. |
413-1248
|
[4] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
CAS
3/4-10 x 3 C Superseded by part number: 87337
|
| 3. |
230-41112
|
[4] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GR/B Superseded by part number: 280375
|
| 4. |
413-1272
|
[1] |
BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5
|
CAS
3/4-10 x 4-1/2 C Superseded by part number: 88007
|
| 5. |
232-53112
|
[3] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
GR/G Superseded by part number: 86512372
|
| 6. |
6596605
|
[2] |
LINK
|
CAS
WA
|
| 7. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 8. |
232-5316
|
[7] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
D22200
|
[1] |
BEARING,25.4mm ID x 36.5mm OD x 22.23mm L
|
CAS
bushing Superseded by part number: 87659928
|
| 10. |
700715071
|
[1] |
OIL SEAL
|
CAS
RING retaining
|
| 11. |
413-8104
|
[8] |
BOLT,Hex, 1/2" - 13 x 6-1/2", Gr 5
|
CAS
1/2-13 x 6-1/2 C Superseded by part number: 9627857
|
| 12. |
230-4118
|
[8] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GR/B
|
| 13. |
700714985
|
[2] |
SPRING
|
CAS
extension
|
| 14. |
700707584
|
[2] |
PAD
|
CAS
neoprene
|
| 15. |
163-41
|
[2] |
SCREW,Sl Hex Wshr Hd, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 x 1-1/4 HWHMS
|
| 16. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 17. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8" bolt size Superseded by part number: 87613283
|
| 18. |
700134603
|
[1] |
GUSSET
|
CAS
WA stop, left
|
| 19. |
434-616
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| 20. |
700129438
|
[2] |
ROD
|
CAS
latch
|
| 21. |
438-11220
|
[4] |
LOCK PIN,3/16" x 1 1/4", Slotted
|
CAS
Superseded by part number: 87020816
|
| 22. |
700712689
|
[2] |
SPRING
|
CAS
compression
|
| 23. |
700706458
|
[1] |
WIRE HARNESS
|
CAS
CABLE, ACC
|
| 24. |
432-1220
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
CAS
Superseded by part number: 87398
|
| 25. |
700706682
|
[2] |
FRONT AXLE
|
CAS
ELBOW male Superseded by part number: 30773V, 222-1845
|
| 26. |
700129838
|
[1] |
HITCH ASSY, TRAILER
|
CAS
WA
|
| 27. |
8798191
|
[1] |
HARNESS
|
CAS
CABLE
|
| 28. |
413-1228
|
[2] |
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 88725
|
| 29. |
515-2363
|
[3] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
line Superseded by part number: 675162
|
| 30. |
515-23159
|
[6] |
CLAMP,5/8", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86594406
|
| 31. |
6811137
|
[1] |
CONTROL UNIT
|
HFI
ASSEMBLY control
|
| 32. |
413-516
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 33. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 34. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 35. |
121-237
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 x 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 36. |
329-286
|
[7] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 37. |
433-1028
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 1 3/4", Gr 5
|
CAS
5/8-11 x 1-3/4 RHSNB Superseded by part number: 280805
|
| 38. |
232-53110
|
[14] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
Superseded by part number: 84180923
|
| 39. |
413-824
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 40. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 41. |
231-5348
|
[3] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 42. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Superseded by part number: 72187207, 88011
|
| 43. |
496-11041
|
[5] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8 Superseded by part number: 86632588
|
| 44. |
433-828
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 x 1-3/4 RHSNB Superseded by part number: 88530
|
| 45. |
700129846
|
[1] |
PIN
|
CAS
|
| 46. |
700129472
|
[1] |
PIN
|
CAS
WA hitch
|
| 47. |
700129844
|
[1] |
ARM
|
CAS
ASSEMBLY, Includes: Ref. 9 ,& 10
|
| 48. |
700129849
|
[2] |
BUSHING
|
CAS
|
| 49. |
700129847
|
[3] |
SUPPORT
|
CAS
WA bale
|
| 50. |
515-23190
|
[2] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86624005
|
| 51. |
700134604
|
[1] |
GUSSET
|
CAS
WA stop, right
|
| 52. |
413-1024
|
[12] |
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 88062
|
