凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (10-012) - WING CART ASSEMBLY (LEFT) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
861 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700134572
|
[1] |
FUNNEL
|
CAS
FRAME WING, WA cart
|
| 2. |
434-616
|
[31] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| 3. |
232-5316
|
[25] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
700129986
|
[1] |
STRAP
|
CAS
WING, adjustment
|
| 5. |
700134586
|
[1] |
STOP
|
CAS
WA WING, left
|
| 6. |
329-286
|
[6] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 7. |
700129942
|
[1] |
ANGLE
|
CAS
mounting, spring
|
| 8. |
700134590
|
[1] |
STRAP
|
CAS
WING, latch
|
| 9. |
409-768
|
[8] |
BOLT,Hex Flg, 3/8" - 16 x 1/2", Spcl
|
CAS
3/8-16 x 1/2 HFSS Superseded by part number: 50215
|
| 10. |
700134583
|
[1] |
FLOOR
|
CAS
WING, left
|
| 11. |
700134582
|
[1] |
CHANNEL
|
CAS
WING, rear
|
