纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.500[04]) - PIPING - HEAT EXCHANGER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1018 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76037559 | [1] | HYDRAULIC HOSE | LEC |
| 2. | 76037558 | [1] | HYDRAULIC HOSE | LEC |
| 3. | 70921076 | [8] | SCREW,3/8"-16 x 1 1/4" | BHB Superseded by part number: 280165 |
| 4. | 8292188 | [4] | CLAMP,Half | LEC Superseded by part number: 86980728 |
| 5. | 12638621 | [8] | WASHER,M10 x 18 x 2 | BHB10X18 Superseded by part number: 17095014 |
| 6. | 14463780 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 5, 75 Duro | LEC Superseded by part number: 353108 |
