纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.510[01]) - FUEL AND OIL TANK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
504 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79112415 | [1] | FUEL TANK | LEC |
| 2. | 79099907 | [1] | SHIM | LEC |
| 3. | 11116031 | [8] | BOLT,Hex, M14 x 45, 10.9, Full Thd | LEC Superseded by part number: 87015765 |
| 4. | 12644931 | [8] | WASHER,14.4mm ID x 32mm OD x 4mm Thk | LEC |
| 5. | 79113729 | [2] | SEAL | LEC |
| 6. | 79113728 | [2] | STRAP | LEC |
| 7. | 13311017 | [6] | SCREW,Pozidriv Oval Hd, Csk, M5 x 16mm, Cl 5.8, Full Thd | IMO |
| 8. | 13336407 | [6] | WASHER | LEC5 |
| 9. | 79113730 | [1] | GASKET | LEC- SIDE RIGHT |
| 10. | 79113731 | [1] | GASKET | LEC- SIDE LEFT |
| 11. | 76033201 | [1] | SEAL | LEC |
