| 1. |
702700234
|
[4] |
TIRE TUBE
|
CAS
|
| 2. |
T52730
|
[24] |
WHEEL BOLT
|
IH
wheel, 9/16-18 Superseded by part number: 86628557
|
| 3. |
481344R91
|
[4] |
WHEEL
|
IH
|
| 4. |
D143405
|
[4] |
CAP
|
CAS
hub Superseded by part number: 137395
|
| 5. |
26971
|
[4] |
WASHER
|
CAS
|
| 6. |
560953R91
|
[4] |
BEARING ASSY,1.375" ID x 2.875" OD x 0.9688"
|
IH
Superseded by part number: 86516471
|
| 7. |
425-1314
|
[4] |
SLOTTED NUT,7/8"-14, G5
|
CAS
Superseded by part number: 84151573
|
| 8. |
26690
|
[4] |
HUB
|
CAS
ASSEMBLY, Includes: Ref. 22 and 23 Superseded by part number: 026690, 026690, NLS
|
| 9. |
300426R91
|
[4] |
BEARING ASSY,45.618 mm ID x 25.4 mm
|
IH
Superseded by part number: 512725
|
| 10. |
491715R91
|
[4] |
OIL SEAL
|
IH
|
| 11. |
700113767
|
[2] |
CASTER
|
CAS
CASTER WA
|
| 12. |
432-824
|
[4] |
COTTER PIN,1/8" x 1 1/2"
|
CAS
Superseded by part number: 80708
|
| 13. |
58644
|
[6] |
SPRING
|
CAS
compression
|
| 14. |
700113781
|
[2] |
CLUTCH PLATE
|
CAS
|
| 15. |
433-644
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 3/4", Gr 5
|
CAS
3/8-16 x 2-3/4 RHSNB Superseded by part number: 280628
|
| 16. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 17. |
231-1406
|
[6] |
LOCK NUT,3/8"-16, GB
|
CAS
|
| 18. |
700129465
|
[4] |
LARGE PLATE
|
CAS
PLATE, LARGE pressure
|
| 19. |
700711025
|
[4] |
CLUTCH PLATE,92mm ID x 161.92mm OD x 3.18mm Thk
|
CAS
friction
|
| 20. |
700113780
|
[2] |
CAP WASHER
|
CAS
|
| 21. |
6597413
|
[8] |
BRONZE BUSHING
|
HFI
BRONZE BUSH bearing
|
| 22. |
130503H
|
[4] |
BEARING CUP
|
IH
CUP Superseded by part number: 86900365
|
| 23. |
165964R1
|
[4] |
BEARING CUP
|
IH
Superseded by part number: 86516462
|
| 24. |
700113861
|
[2] |
TUBE,95.25 mm OD, 300 mm Length
|
CAS
extension
|
| 25. |
413-1288
|
[2] |
BOLT,Hex, 3/4" - 10 x 5-1/2", Gr 5
|
CAS
3/4-10 x 5-1/2 C Superseded by part number: 86507002
|
| 26. |
230-41112
|
[2] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GR/B Superseded by part number: 280375
|
| 27. |
6595052
|
[2] |
WASHER,76.99mm ID x 101.6mm OD x 1.8mm Thk
|
CAS
|
