凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (10-026) - HYDRAULIC ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
992 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700715531
|
[1] |
CYLINDER
|
CAS
ASSEMBLY hydraulic
|
| 2. |
218-775
|
[2] |
PLUG,3/4"-16, 37 Degree
|
CAS
Superseded by part number: 86511868
|
| 3. |
515-23190
|
[2] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86624005
|
| 4. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 5. |
232-5316
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
700715222
|
[1] |
HOSE
|
CAS
hydraulic
|
| 7. |
700105142
|
[1] |
GROMMET
|
CAS
PLASTIC, trim
|
| 8. |
1714682
|
[1] |
HOSE
|
CAS
hydraulic
|
| 9. |
237-6008
|
[2] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
Superseded by part number: 128825
|
| 10. |
218-5106
|
[2] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
Includes: Ref. 9 Superseded by part number: 72186176, 128830
|
| 11. |
705574
|
[2] |
WASHER,1 1/8" x 2" x .156", HDN
|
CAS
|
