凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (10-032) - BALE SHIFT BAR AND LINKAGE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
353 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-1252
|
[2] |
BOLT,Hex, 3/4" - 10 x 3-1/4", Gr 5
|
CAS
3/4-10 x 3-1/4 C Superseded by part number: 88747
|
| 2. |
230-41112
|
[2] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-1 OHTLN GR/B Superseded by part number: 280375
|
| 3. |
700129813
|
[1] |
ARM
|
CAS
WA rear
|
| 4. |
705566
|
[4] |
WASHER
|
IH
hardened plain, 3/4
|
| 5. |
700716820
|
[2] |
FITTING
|
CAS
ZERK, special, #10-32 x 1/2
|
| 6. |
7713506
|
[1] |
END
|
CAS
ROD ASSEMBLY, right hand thread, Includes: Ref. 5
|
| 7. |
425-1512
|
[1] |
JAM NUT,Jam, 3/4"-10, G5
|
IH
3/4-16 HJN GR2 Superseded by part number: 219758
|
| 8. |
700129832
|
[1] |
ROD
|
CAS
TIE
|
| 9. |
7774375
|
[1] |
NUT
|
CAS
3/4-16 HJN, LH GR2
|
| 10. |
7713498
|
[1] |
END
|
CAS
ROD ASSEMBLY, left hand thread, Includes: Ref. 5
|
| 11. |
700129829
|
[2] |
PIN
|
CAS
WA
|
| 12. |
700710148
|
[8] |
BOLT,Hex Flg, 5/8" - 11 x 1 3/4", Gr 8
|
IH
5/8-11 x 1-3/4 HFS GR8 Superseded by part number: 360-1028
|
| 13. |
232-53110
|
[8] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
Superseded by part number: 84180923
|
| 14. |
495-21138
|
[2] |
WASHER,1 1/4"
|
CAS
hardened plain, 1-1/4 Superseded by part number: 87370
|
| 15. |
700129812
|
[1] |
ARM
|
CAS
WA front
|
| 16. |
425-1016
|
[2] |
NUT,1"-8, G5
|
CAS
Superseded by part number: 9849633
|
| 17. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 18. |
52258
|
[2] |
BUSHING
|
CAS
1 x 14 gauge NRMB
|
| 19. |
495-81205
|
[4] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 x 14 gauge NRMB
|
| 20. |
700129834
|
[1] |
BEAM ASSY.
|
CAS
PUSHER WA
|
