纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.550[01]) - ENGINE COOLING SYSTEM - WATER RADIATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
823 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79109157 | [1] | RADIATOR | LEC- ASSY SEE TAV.4 |
| 2. | 12645031 | [8] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 3. | 79112352 | [1] | CONVEYOR | LEC- ASSY |
| 4. | 79112351 | [2] | SEALING ELEMENT | LEC |
| 5. | 79066505 | [1] | GRILLE | LEC- RIGHT |
| 6. | 79113136 | [2] | GUARD | LEC |
| 7. | 79113137 | [2] | STRAP | LEC |
| 8. | 16043431 | [24] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 9. | 14496531 | [16] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 10. | 79066506 | [1] | GRILLE | LEC- LEFT |
| 11. | 79093121 | [1] | SUPPORT | LEC- RIGHT |
| 12. | 79093124 | [1] | SUPPORT | LEC- LEFT |
| 13. | 10615679 | [12] | LOCK WASHER,Ext Tooth, M8 | BHB8 Superseded by part number: 10615671 |
| 14. | 16042931 | [1] | BOLT,Hex, M8 x 1.25 x 10mm, Cl 10.9, Full Thd | BHB |
