纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.550[02]) - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
827 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79112646 | [1] | GUARD | LEC- RIGHT |
| 2. | 79112645 | [1] | GUARD | LEC- LEFT |
| 3. | 79113458 | [1] | GUARD | LEC- LOWER |
| 4. | 79112725 | [1] | GUARD | LEC- SIDE LEFT |
| 5. | 79112724 | [1] | GUARD | LEC- SIDE RIGHT |
| 6. | 79100440 | [1] | BRACKET | LEC |
| 7. | 4977098 | [2] | ISOLATOR | LEC |
| 8. | 4977099 | [2] | WASHER | LEC Superseded by part number: 75223895 |
| 9. | 4977100 | [1] | SPACER | LEC Superseded by part number: 75223896 |
| 10. | 12577521 | [1] | NUT,M12 x 1.75 | LEC |
| 11. | 12648531 | [1] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 12. | 11113831 | [3] | SCREW,Hex, M12 x 80mm, Cl 10.9 | LEC Superseded by part number: 11113821, 412085 |
| 13. | 12626231 | [3] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 14. | 11106231 | [4] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 15. | 16043431 | [12] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 16. | 14496531 | [14] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 17. | 79110359 | [1] | WASHER | LEC |
| 18. | 4974337 | [4] | PAD | LEC Superseded by part number: 76069292 |
| 19. | 4974343 | [4] | WASHER | LEC Superseded by part number: 79111680 |
| 20. | 4974344 | [2] | SPACER | LEC |
| 21. | 76041379 | [1] | BRACKET | LEC |
| 22. | 16044031 | [2] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9 | LEC Superseded by part number: 9780069 |
| 23. | 12645031 | [2] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 24. | 16104121 | [2] | NUT,M8 x 1.25, Cl 10 | LEC Superseded by part number: 17152821 |
