纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.040[01]) - CRANKCASE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
744 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4860550 | [1] | CYLINDER BLOCK | BRE- ASSY |
| 2. | 4851814 | [14] | SCREW | TOR |
| 3. | 98471160 | [1] | BUSHING | BRE-Vandervell |
| 4. | 98471161 | [5] | BUSHING | LEC-Vandervell |
| 5. | 98471162 | [1] | BUSHING | BRE-Vandervell |
| 6. | 16991170 | [6] | PLUG | LEC36X9 |
| 7. | 99434233 | [1] | PLUG | MOD22X1,5X10 |
| 8. | 14328301 | [2] | PLUG,M12, Tapered | TOR |
| 8. | 14329301 | [1] | PLUG,M42, Tapered | TTF42X13 |
| 8. | 14328501 | [1] | PLUG,M16, Tapered | TOR |
| 9. | 10269501 | [1] | PLUG | JES14X1,5 |
| 9. | 14323911 | [8] | PLUG | TTF10X1,25X14 |
| 9. | 14326101 | [1] | PLUG | BAS8X1,25 |
| 9. | 14324111 | [1] | PLUG | TTF14X1,5 |
| 10. | 4731414 | [1] | PLUG | MOD20X1,5X13 |
| 11. | 10265460 | [1] | SEAL | TOR49X42X1,5 |
| 12. | 14328801 | [1] | PLUG,M22, Tapered | JES |
| 13. | 4665029 | [1] | PLUG | TORM42 x 1.5 |
