| 1. |
433-824
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
Superseded by part number: 280420, 72187237
|
| 2. |
80679
|
[8] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 3. |
425-108
|
[10] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 4. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
ASSEMBLY, Includes: Ref. 5
|
| 5. |
712158
|
[2] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
spherical Superseded by part number: 47577203
|
| 6. |
700710542
|
[1] |
SEALING RING
|
CAS
|
| 7. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 8. |
700123332
|
[1] |
SHAFT
|
CAS
Superseded by part number: 700153339
|
| 9. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 87868
|
| 10. |
714360
|
[2] |
FLANGED BEARING
|
IH
flange
|
| 11. |
413-1236
|
[1] |
BOLT,Hex, 3/4" - 10 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87403
|
| 12. |
705566
|
[1] |
WASHER
|
IH
hardened plain, 3/4
|
| 13. |
232-41112
|
[1] |
NUT,3/4"-10, GC
|
CAS
Superseded by part number: 280375
|
| 14. |
7852866
|
[2] |
BUSHING
|
CAS
2 x 18 gauge NRMB
|
| 15. |
740407
|
[3] |
BRUSH, COMMUTATOR
|
CAS
BRUSH 2 x 10 gauge NRMB
|
| 16. |
8052177
|
[1] |
WASHER
|
CAS
|
| 17. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
Superseded by part number: 80710
|
| 18. |
700706643
|
[1] |
KEY
|
CAS
1/2 x 1/2 x 1-3/4 GIB
|
| 19. |
700112925
|
[1] |
HUB
|
CAS
splined, 28 tooth
|
| 20. |
654437R91X
|
[1] |
CHAIN,#80, 93 Links x 25.4mm = 2362.2mm
|
CAS
roller, #80 (10 foot bulk)
|
| 21. |
241-1418
|
[1] |
SPRING CLIP
|
CAS
CONNECTOR link, #80 R/C (W/C Pins)
|
| 22. |
6823512
|
[2] |
SPACER
|
CAS
|
| 23. |
747931
|
[1] |
DECAL
|
CAS
IDLER, 12 tooth Superseded by part number: 51200277, 51200277, NLS
|
| 24. |
52183
|
[1] |
BUSHING
|
CAS
3/4 x 18 gauge NRMB Superseded by part number: Z52183
|
| 25. |
700123330
|
[1] |
CLEVIS
|
CAS
|
| 26. |
7770878
|
[1] |
BOLT,Sq Nk, 1/2" - 13 x 7", Gr 5, Full Thd
|
CAS
1/2-13 x 7 FT RHSNB
|
| 27. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 28. |
413-1264
|
[1] |
BOLT,Hex, 3/4" - 10 x 4", Gr 5
|
CAS
3/4-10 x 4 C Superseded by part number: 280210
|
| 29. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 30. |
425-1012
|
[1] |
NUT,3/4"-10, G5
|
CAS
Superseded by part number: 280954
|
| 31. |
T39594
|
[1] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
Superseded by part number: 87029275
|
| 32. |
700123336
|
[1] |
SPROCKET ASSY.
|
CAS
16 tooth, Includes: Ref. 31 Superseded by part number: 95-81182, 700153519
|
| 33. |
95-81182
|
[3] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
3/4 x 14 gauge NRMB
|
