纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (1.277[04]) - SPROCKET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
699 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79087681 | [2] | HUB | LEC Superseded by part number: 93201922 |
| 2. | 586780 | [2] | RING | LEC |
| 3. | 586931 | [2] | NUT | LEC |
| 4. | 586932 | [2] | LOCKING PLATE | LEC |
| 5. | 76038413 | [2] | SUPPORT | LEC- ASSY Superseded by part number: 76038411, 10837710 |
| 6. | 594322 | [2] | THRUST PLATE | LEC |
| 7. | 594323 | [2] | WASHER | LEC |
| 8. | 594325 | [2] | NUT | LEC |
| 9. | 594326 | [1] | HOUSING | GI0,8 Superseded by part number: 595431, 595431, 75128836 |
| 9. | 594327 | [1] | | LEC1,0 Superseded by part number: 75128837, 75128837, 80594327 |
| 9. | 594328 | [1] | SHIM,1mm Thk | LEC1,2 |
| 9. | 594329 | [1] | SHIM,1.2mm Thk | LEC1,4 |
| 9. | 594330 | [1] | SHIM,1.4mm Thk | LEC1,5 |
| 9. | 594331 | [1] | SHIM,1.5mm Thk | LEC0,3 |
| 10. | 10206610 | [2] | KEY | MKT16X10 |
| 11. | 14496731 | [18] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 12. | 79087989 | [54] | NUT | LEC |
| 13. | 14468580 | [2] | O-RING,0.139" Thk x 8.234" ID, -267, Cl 5, 75 Duro | LEC(M209.1 ID x 3.53 Thk) Superseded by part number: 70924143 |
| 14. | 15541134 | [18] | BOLT,Hex, M12 x 1.25 x 65mm, Cl 10.9 | LEC Superseded by part number: 15541131, 15541131 |
| 15. | 79087682 | [54] | BOLT,M22 x 1.5 x 1.5mm, Cl 10.9 | LEC |
| 16. | 79031688 | [2] | STABILIZER BAR | LEC |
| 17. | 586743 | [2] | RETAINER | MOD |
| 18. | 79031520 | [2] | HUB | LEC Superseded by part number: 93200899, 93200899, 93201922 |
| 19. | 79031756 | [2] | BOX | LEC |
| 20. | 79031757 | [2] | TAPERED ROLLER BEARING,110mm ID x 170mm OD x 38mm W | LEC |
| 21. | 79031758 | [2] | TAPERED ROLLER BEARING,169.97mm ID x 239.97mm OD x mm W | LEC |
| 22. | 76027990 | [18] | TOOTHED SECTOR | LEC- IN ALTERNATIVE |
| 22. | 79087680 | [18] | TOOTHED SECTOR | LEC- IN ALTERNATIVE Superseded by part number: 76027990 |
| 23. | 76029105 | [4] | SEAL,197mm ID x 245mm OD x 41mm Thk | LEC |
| 24. | 79031761 | [2] | RING NUT | LEC |
| 25. | 10837710 | [4] | DOWEL,M10 x 25 | TTF |
| 26. | 93201922 | [1] | KIT | LEC |
