纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (1.277[15]) - REAR TRANSMISSION - CONTROL VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79041977 | [1] | SPRING | LEC |
| 2. | 79054402 | [2] | ELBOW | LEC- ASSY Superseded by part number: 76344 |
| 3. | 79089077 | [1] | BODY | LEC |
| 4. | 79028953 | [2] | SEAL,16.45mm ID x 25.55mm OD x 2.1mm Thk | LEC |
| 5. | 79096127 | [2] | PLUG | LEC |
| 6. | 79084957 | [2] | PLUG | LEC |
| 7. | 10118740 | [4] | PLUG,M14 x 1.5 x 15, Brass | LECAssy |
| 8. | 79086322 | [2] | SEAL,22.7mm ID x 30mm OD x 2mm Thk | LEC |
| 9. | 14455581 | [1] | O-RING,63.22mm ID x 1.78" Width | LEC |
| 10. | 79056442 | [2] | SPRING | LEC |
| 11. | 70932571 | [1] | O-RING | LEC Superseded by part number: 14456981 |
| 12. | 14454381 | [2] | O-RING,31.47mm ID x 1.78" Width | LEC |
| 13. | 79085680 | [2] | SPRING | LEC |
| 14. | 79056440 | [2] | RING | LEC |
| 15. | 79066940 | [2] | HYD CONNECTOR | LEC- ASSY |
| 16. | 76031332 | [2] | SPACER | LEC |
| 18. | 14437785 | [1] | O-RING,11.3mm ID x 2.4mm | LEC |
| 19. | 14453881 | [1] | O-RING,23.52mm ID x 1.78" Width | LEC(M23.52 ID x 1.78 Thk) |
| 17. | 14437885 | [1] | O-RING,13.30mm ID x 2.40mm | LEC |
