| 1. |
738468
|
[3] |
O-RING
|
IH
|
| 2. |
7872740
|
[2] |
HOSE
|
CAS
hydraulic
|
| 3. |
700712122
|
[1] |
CYLINDER
|
CAS
hydraulic
|
| 4. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Superseded by part number: 76344, 72186128
|
| 5. |
6280036
|
[5] |
CLAMP
|
CAS
|
| 6. |
CAS727958
|
[4] |
PAD
|
CAS
|
| 7. |
439-11032
|
[1] |
HEADED PIN,15.88mm OD x 50.8mm L
|
CAS
clevis, 5/8 x 2
|
| 8. |
432-1020
|
[2] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
Superseded by part number: 86523851
|
| 9. |
51200289
|
[1] |
FITTING
|
CAS
hydraulic, Includes: Ref. 26
|
| 10. |
700701624
|
[1] |
ELBOW
|
CAS
fitting hydraulic
|
| 11. |
218-5107
|
[1] |
90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB
|
CAS
Incl. Ref. 26 Superseded by part number: 72186142, 164910
|
| 12. |
700707841
|
[1] |
HYD CONNECTOR
|
CAS
Includes: Ref. 1 Superseded by part number: 139398
|
| 13. |
700706387
|
[1] |
CONTROL VALVE
|
CAS
Superseded by part number: 700709986
|
| 14. |
700134434
|
[1] |
PLATE ASSY.
|
CAS
spacer
|
| 15. |
700710067
|
[2] |
HYDRAULIC HOSE,6.35 mm ID x 2000.00 mm, SAE 100R7
|
CAS
|
| 16. |
700129085
|
[2] |
CLAMP
|
CAS
|
| 17. |
529070
|
[2] |
CABLE TIE,368.3mm L
|
NH
TIE nylon
|
| 18. |
7846389
|
[1] |
RESTRICTOR
|
CAS
|
| 19. |
746677
|
[4] |
CAP
|
CAS
|
| 20. |
700710060
|
[2] |
HOSE
|
CAS
hydraulic
|
| 21. |
413-660
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5
|
CAS
3/8-16 x 3-3/4 C Superseded by part number: 86505979
|
| 22. |
231-4116
|
[2] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 23. |
433-620
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 24. |
232-5316
|
[6] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 25. |
111-361
|
[1] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5
|
CAS
Superseded by part number: 9706752
|
| 26. |
237-6010
|
[2] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
Superseded by part number: 72186125, 167269
|
| 27. |
700713978
|
[1] |
TUBE
|
CAS
LINE hydraulic, front
|
| 28. |
515-2363
|
[6] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
1/4 Superseded by part number: 675162
|
| 29. |
121-108
|
[6] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 x 1 HWHMS
|
| 30. |
232-5315
|
[6] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 31. |
413-628
|
[4] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 32. |
700710065
|
[1] |
TUBE
|
CAS
LINE hydraulic
|
| 33. |
700710063
|
[2] |
TUBE
|
CAS
LINE hydraulic
|
| 34. |
63495
|
[1] |
CLIP
|
CAS
PIN clevis, 5/8 x 2-1/2
|
| 35. |
329-286
|
[1] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
