凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (08-004) - HYDRAULIC CONTROL VALVE ASSEMBLY (BALE DENSITY), 700706387 VALVE ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
927 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700710176
|
[1] |
COIL
|
CAS
12 V
|
| 2. |
700706156
|
[1] |
NUT
|
CAS
Superseded by part number: 86516836
|
| 3. |
700706386
|
[1] |
CONTROL VALVE
|
CAS
(optional), Includes: Ref. 1, 2, 4, 5 and 13 Superseded by part number: 277064
|
| 4. |
149942C1
|
[5] |
SEAL KIT
|
IH
Superseded by part number: 86508168
|
| 5. |
700706155
|
[1] |
VALVE PRESSURE RELIE
|
CAS
|
| 6. |
700707832
|
[1] |
VALVE PRESSURE RELIE
|
CAS
|
| 7. |
700706609
|
[1] |
ORIFICE
|
CAS
PLUG
|
| 8. |
700706604
|
[3] |
PLUG
|
CAS
O-RING, Includes: Ref. 9
|
| 9. |
237-6008
|
[3] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
Superseded by part number: 128825
|
| 10. |
700706602
|
[1] |
PLUG
|
CAS
cartridge, Includes: Ref. 4 Superseded by part number: 920018484
|
| 11. |
700706153
|
[2] |
HYDRAULIC VALVE
|
CAS
|
| 12. |
700706151
|
[2] |
NUT
|
CAS
Superseded by part number: 87033382
|
| 13. |
700707826
|
[1] |
REPAIR KIT
|
CAS
KIT, housing
|
