纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (6.711[02]) - ELECTRIC WIRING - ELECTRICAL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
849 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 10450490 | [5] | CLAMP,16mm, Coat, 9mm Bolt Hole, P Type | LEC9mm hole dia. Superseded by part number: |
| 2. | 10450990 | [3] | CLAMP,26mm, Coat, 9mm Bolt Hole, P Type | LEC26 Superseded by part number: 86637977 |
| 3. | 12598374 | [17] | LOCK WASHER | TTF Superseded by part number: 86632601 |
| 4. | 16043331 | [1] | SCREW,Hex, M8 x 1.25 x 18mm, Cl 10.9, Full Thd | LEC |
| 5. | 10450790 | [5] | RETAINER COLLAR,22mm, Coat, 9mm Bolt Hole, P Type | LEC22X9 Superseded by part number: 10450990 |
| 6. | 16043031 | [19] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 7. | 10448890 | [4] | CLAMP,36mm, Coat, P Type | LEC36 Superseded by part number: |
| 8. | 4982514 | [1] | CABLE TIE | LEC370 Superseded by part number: 87615202 |
| 9. | 79044800 | [1] | CLIP,M20 | LEC Superseded by part number: 86637979 |
