纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (6.712[03]) - ELECTRIC COMPONENTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
209 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79086491 | [2] | BRACKET | LEC |
| 2. | 79102125 | [1] | HEADLAMP | LEC- RIGHT ASSY |
| 2. | 79092952 | [1] | HEADLAMP | TOR- LEFT ASSY |
| 3. | 16043331 | [6] | SCREW,Hex, M8 x 1.25 x 18mm, Cl 10.9, Full Thd | LEC |
| 4. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 5. | 79109449 | [1] | SPACER | LEC |
| 6. | 79073823 | [2] | PAD | LEC |
| 7. | 79109450 | [1] | WASHER | LEC |
| 8. | 79109451 | [1] | NUT | LEC Superseded by part number: 79073825 |
| 9. | 79069460 | [1] | BULB | LEC Superseded by part number: 14151690 |
| 10. | 79107914 | [1] | LENS | LEC |
| 11. | 12645031 | [4] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 12. | 79114713 | [1] | HORN | LEC Superseded by part number: 87357734, 87391178 |
