| 1. |
700123726
|
[4] |
SHIM
|
CAS
0.46/.018
|
| 2. |
61-43820
|
[12] |
HEX SOC SCREW,FLAT, 3/8" x 1-1/4"
|
CAS
3/8-16 x 1-1/4 HSFCHCS SPL Superseded by part number: 82039
|
| 3. |
492-11038
|
[48] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 4. |
425-106
|
[48] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 5. |
700123724
|
[4] |
RAIL
|
CAS
hardened
|
| 6. |
700129645
|
[1] |
DRIVE DOG
|
CAS
HAY, wa left
|
| 7. |
700129640
|
[3] |
DRIVE DOG
|
CAS
HAY, wa
|
| 8. |
118-140
|
[18] |
PLOW BOLT,3/8"-16 x 1 1/8", G5
|
CAS
plow, 3/8-16 x 1-1/4
|
| 9. |
496-11041
|
[18] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8 Superseded by part number: 86632588
|
| 10. |
700129586
|
[3] |
LARGE PLATE
|
CAS
PLATE, LARGE wear
|
| 11. |
700713962
|
[1] |
KNIFE,794mm L x 63.5mm W x 7.94mm Thk
|
CAS
|
| 12. |
700129647
|
[4] |
PROTECTOR
|
CAS
ASSEMBLY NEEDLE, Includes: Ref. 20
|
| 13. |
413-1232
|
[2] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5
|
CAS
Superseded by part number: 88557
|
| 14. |
705566
|
[2] |
WASHER
|
IH
hardened plain, 3/4
|
| 15. |
326-824
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 8
|
IH
|
| 16. |
80679
|
[9] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 17. |
705541
|
[9] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 18. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| 19. |
700129646
|
[1] |
DRIVE DOG
|
CAS
HAY, wa right
|
| 20. |
37-1612
|
[8] |
DOWEL,3/8" x 3/4"
|
CAS
PIN, 3/8 x 3/4
|
| 21. |
707448
|
[5] |
BOLT
|
CAS
plow, 1/2-13 x 1-1/2 Superseded by part number: 419-3824
|
| 22. |
425-108
|
[5] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 23. |
700123494
|
[1] |
SUPPORT
|
CAS
|
| 24. |
52183
|
[2] |
BUSHING
|
CAS
3/4 x 18 gauge NRMB Superseded by part number: Z52183
|
| 25. |
95-81051
|
[2] |
WASHER,19.84mm ID x 31.75mm OD x 3.81mm Thk
|
CAS
3/4 x 10 gauge NRMB
|
| 26. |
164-54
|
[12] |
HEX SOC SCREW,Flat Hd, 3/8" - 16 x 1 3/4"
|
CAS
3/8-16 x 1-3/4 HSFCHCS SPL Superseded by part number: 87846
|
| 27. |
700123725
|
[2] |
RAIL
|
CAS
|
| 28. |
700123727
|
[4] |
ANGLE
|
CAS
SHIELD
|
| 29. |
700137654
|
[4] |
DOG
|
CAS
HAY DOG
|
| 30. |
439-11060
|
[4] |
HEADED PIN,15.88mm OD x 95.25mm L
|
CAS
clevis, 5/8 x 3-3/4
|
| 31. |
396-21066
|
[4] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8" bolt size Superseded by part number: 87613283
|
| 32. |
700706376
|
[4] |
SPRING
|
CAS
torsion Superseded by part number: 84806594
|
| 33. |
S120261
|
[4] |
PIN
|
CAS
wire hair cotter, .148
|
