纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (3.440[01]) - LIFT CYLINDERS PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
764 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76032256 | [1] | RIGID TUBE | LEC |
| 2. | 76032255 | [1] | RIGID TUBE | LEC |
| 3. | 76033377 | [2] | FLEXIBLE HOSE | LEC |
| 4. | 14420231 | [16] | HEX SOC SCREW,M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC |
| 5. | 79050056 | [4] | FLANGE | LEC Superseded by part number: 71404407 |
| 6. | 70924110 | [2] | O-RING | LEC3,53X24,99 Superseded by part number: 98458442 |
| 7. | 11106231 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 8. | 79005244 | [2] | WASHER,10.6mm ID x 25mm OD x 6mm Thk | LEC |
| 9. | 79084667 | [1] | BRACKET | LEC |
| 10. | 79076680 | [1] | CLAMP | LEC |
| 11. | 8292188 | [8] | CLAMP,Half | LEC Superseded by part number: 86980728 |
| 12. | 11701721 | [1] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 13. | 79091328 | [3] | BRACKET | LEC |
| 14. | 11107531 | [1] | SCREW,Hex, M10 x 65mm, Cl 10.9 | LEC |
| 15. | 16044731 | [3] | SCREW,Hex, M8 x 1.25 x 75mm, Cl 10.9 | LEC Superseded by part number: Z1232960 |
| 16. | 14420331 | [8] | HEX SOC SCREW,M10 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC |
| 17. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 18. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 19. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 20. | 70924200 | [4] | O-RING | LEC3,53X32,92 Superseded by part number: 14463780 |
