纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (3.461[01]) - MAIN FRAME New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
804 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76038379 | [1] | FRAME | LEC- ASSY |
| 2. | 79087774 | [2] | BUSHING | LEC |
| 3. | 8292010 | [2] | BUSHING,76.2mm ID x 85mm OD x 50mm L | LEC |
| 4. | 4974163 | [6] | PLUG | LEC |
| 5. | 13407211 | [2] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 6. | 79114686 | [2] | FLEXIBLE HOSE,8.00 mm ID x 355.00 mm | LEC |
| 7. | 10791321 | [2] | THIN NUT,Thin, M14 x 1.5, Cl 05 | MKT14X1,5X8 Superseded by part number: 16980331 |
| 8. | 79067014 | [2] | HYD CONNECTOR | LEC- ASSY |
| 9. | 15997531 | [12] | BOLT,Hex, M24 x 2 x 90mm, Cl 10.9 | MKT Superseded by part number: 15997537 |
| 10. | 76002741 | [12] | WASHER | LEC Superseded by part number: 79009899 |
| 11. | 14437585 | [1] | O-RING,8.00mm ID x 1.50mm | IMO |
