纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (2.346[04]) - TRACK IDLER - CYLINDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
791 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4951546 | [2] | SPRING | LEC |
| 2. | 76012378 | [2] | SPRING | LEC |
| 3. | 76010251 | [1] | CYLINDER | LEC- RIGHT ASSY |
| 3. | 76010253 | [1] | CYLINDER | LEC- LEFT ASSY |
| 4. | 76010257 | [2] | PISTON | LEC |
| 5. | 79065575 | [2] | SEAL,80mm ID x 100mm OD x 12mm Thk | LEC |
| 6. | 79065577 | [2] | SEAL,80mm ID x 100.25mm OD x 10mm Thk | LEC |
| 7. | 79033919 | [2] | DISC | LEC |
| 8. | 594692 | [2] | SHEET | LEC |
| 9. | 587255 | [2] | NUT | LEC |
| 10. | 587256 | [2] | WASHER | LEC |
| 11. | 14496631 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 12. | 15970731 | [2] | BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd | LEC |
| 13. | 76009442 | [2] | HYDRAULIC VALVE | LEC- ASSY |
| 14. | 79043802 | [2] | HYDRAULIC VALVE | LEC- ASSY |
| 15. | 13407211 | [1] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 22. | 20063470 | [1] | BALL | TTF7,938 Superseded by part number: 86642304 |
| 23. | 10389511 | [1] | SCREW,Sl Pan Hd, M5 x 14mm, Cl 5.8 | LEC Superseded by part number: 10389514 |
| 24. | 11195471 | [1] | LOCK WASHER | LEC5,1X1,1 Superseded by part number: 10569179 |
| 26. | 20063460 | [1] | BALL,7.14mm OD, Gr 100 | LEC7,144 |
