纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (5.601[02]) - HOODS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
662 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79113946 | [1] | TIE-ROD | LEC- RIGHT |
| 1. | 79113948 | [1] | TIE-ROD | LEC- LEFT |
| 2. | 79109462 | [2] | RETAINER | LEC |
| 3. | 79112294 | [4] | HALF-HINGE | LEC |
| 4. | 79113721 | [4] | HINGE | LEC |
| 5. | 10902231 | [8] | SCREW,Hex, M6 x 16mm, Cl 10.9 | LEC Superseded by part number: 86639037 |
| 6. | 14496431 | [8] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 7. | 11112231 | [8] | SCREW,Hex, M12 x 1.75 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 398792 |
| 8. | 14496731 | [8] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 9. | 12626231 | [2] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 10. | 10796401 | [6] | COTTER PIN,M3.2 x 18 | TTF Superseded by part number: |
| 11. | 14496531 | [16] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 12. | 10615679 | [8] | LOCK WASHER,Ext Tooth, M8 | BHB8 Superseded by part number: 10615671 |
| 13. | 16043631 | [8] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHB Superseded by part number: 43234 |
| 14. | 79092269 | [1] | SHIM | LEC |
| 15. | 79113724 | [4] | PIN | LEC |
| 16. | 79068087 | [8] | BUSHING | LEC |
| 17. | 14496631 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
