纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (5.601[03]) - HOODS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79115067 | [1] | SIDE PANEL | LECLOWER RIGHT |
| 1. | 79115063 | [1] | SIDE PANEL | LECLOWER LEFT |
| 2. | 12626231 | [4] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 3. | 12577221 | [4] | LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 10, ZND | LEC10X1,5X12,3 |
| 4. | 14508287 | [4] | PLUG | LEC50 |
| 5. | 79115062 | [4] | SCREW,M10 x 1.5 x 1.5mm | LEC |
| 6. | 79115060 | [2] | SUPPORT | LEC |
| 7. | 11701721 | [4] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 8. | 11106431 | [6] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
| 9. | 14496631 | [6] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
