纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (5.601[05]) - HOODS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
188 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79113598 | [1] | FRAME | LEC- ASSY |
| 2. | 79025958 | [8] | PLUG | LEC |
| 3. | 4976139 | [8] | PLUG | MKT |
| 4. | 79095797 | [3] | PLATE | LEC |
| 5. | 14622387 | [3] | PLUG | LEC9,5X2,5 |
| 6. | 13273517 | [6] | SCREW,Cross Pan Hd, M5 x 15mm | LEC5X0,8X15 Superseded by part number: 13273511 |
| 7. | 11391531 | [8] | BOLT,Hex, M16 x 1.5 x 45mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11391537 |
| 8. | 79005240 | [8] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 9. | 79114504 | [2] | GASKET | LEC |
| 10. | 79114505 | [2] | STRAP | LEC |
| 11. | 13311217 | [8] | SCREW,Pozidriv Oval Hd, Csk, M5 x 20mm, Cl 5.8, Full Thd | IMO |
| 12. | 13336407 | [8] | WASHER | LEC5 |
| 13. | 76042233 | [1] | BLOCK | NH |
