凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (05-006) - CLUTCH DOG ASSEMBLY, S.N. CFH0163715 AND LATER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
355 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6524623
|
[1] |
ROLLER,41.28mm OD x 18.67mm L
|
CAS
|
| 2. |
135-358
|
[1] |
GROOVED PIN,1/4" x 1 1/4", Type F
|
CAS
|
| 3. |
6524649
|
[1] |
PIN
|
CAS
clutch
|
| 4. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 x 45 Deg. ZERK Superseded by part number: 87569
|
| 5. |
700134412
|
[1] |
ARM
|
CAS
CLUTCH, Includes: Ref 1, 2, 3 and 4)
|
| 6. |
700712882
|
[2] |
BOLT,Hex Flg, 1/2" - 13 x 2 1/4", Gr 8
|
CAS
1/2-13 x 2-1/4 HFS GR8
|
| 7. |
231-5148
|
[2] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 8. |
758268
|
[1] |
SPRING
|
CAS
extention
|
| 9. |
700138179
|
[1] |
SUPPORT
|
HFI
spring
|
| 10. |
700138196
|
[1] |
ARM
|
HFI
ARM WA clutch
|
| 11. |
069526
|
[1] |
SCREW
|
CAS
3/8-16 x 3/4 HDPHSSS NP
|
| 12. |
700129542
|
[1] |
SHAFT
|
CAS
clutch
|
