| 1. |
433-824
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
Superseded by part number: 280420, 72187237
|
| 2. |
329-288
|
[8] |
FLANGE NUT,Flg, 1/2"-13, G8
|
CAS
|
| 3. |
700717917
|
[1] |
BEARING ASSY,44.45 mm ID x 96 mm OD x 34.93 mm
|
CAS
BEARING ASSEMBLY, Includes: Ref. 4
|
| 4. |
714113
|
[1] |
SPHERICAL BEARING,1.75" ID x 85 mm OD
|
CAS
spherical Superseded by part number: 47577169, 47577157
|
| 5. |
616154R92
|
[4] |
BEARING, ROLLER, CYL,16 mm
|
IH
cylindrical Superseded by part number: 84356151
|
| 6. |
700124038
|
[8] |
BUSHING,16.27mm ID x 34.92mm OD x 10mm L
|
CAS
BEARING
|
| 7. |
700124036
|
[2] |
LINK CONROD
|
CAS
ASSEMBLY, Includes: Ref. 5
|
| 8. |
852947
|
[6] |
BUSHING
|
CAS
2-1/4 x 14 gauge NRMB
|
| 9. |
700716611
|
[1] |
BEARING ASSY,55.56 mm ID x 111.91 mm OD x 31 mm
|
CAS
ASSEMBLY, Includes: Ref. 12
|
| 10. |
700137337
|
[1] |
SPROCKET ASSY.
|
CAS
WA 80C35 tooth
|
| 11. |
700715751
|
[1] |
NUT
|
CAS
STAKE
|
| 12. |
700704263
|
[1] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
spherical Superseded by part number: 76451
|
| 13. |
700137336
|
[1] |
SPACER
|
CAS
|
| 14. |
413-1036
|
[4] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 x 2-1/4C Superseded by part number: 88556
|
| 15. |
232-41110
|
[4] |
NUT,5/8"-11, GC
|
CAS
Superseded by part number: 85700693
|
