沃尔沃零件查询MD100A; TMD100A; TMD100AK; TMD100A-CC; MD100B; MD100BK; MD100B-CCEngineOil Filter and Installation Components: 820513EPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
465 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
820513
|
[1] |
Bracket
|
See group 2B
|
| 1. |
|
|
|
|
| 8. |
18706
|
[5] |
Gasket
|
|
| 9. |
956571
|
[3] |
Hex. socket screw
|
See group 2B
|
| 11. |
11992
|
[4] |
Gasket
|
See group 2B
|
| 12. |
925057
|
[1] |
O-ring
|
See group 2B
|
| 13. |
820538
|
[1] |
Oil feed hose
|
|
| 14. |
804478
|
[2] |
Hollow screw
|
|
| 15. |
957184
|
[2] |
Gasket
|
|
| 16. |
957185
|
[2] |
Gasket
|
|
| 17. |
925060
|
[2] |
O-ring
|
|
| 18. |
940162
|
[3] |
Hexagon screw
|
|
| 19. |
942336
|
[3] |
Spring washer
|
|
| 20. |
423067
|
[2] |
Nipple
|
|
| 21. |
4785974
|
[2] |
Oil filter
|
|
| 22. |
|
|
|
See group 2B
|
