凯斯零件查询(BTX11) - CASE IH BALE THROWER (1/02-) (70.280.02) - APRON, UPPER & LOWER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
320 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 11. |
86635682
|
[1] |
RAMP
|
PA
|
| 17. |
86641544
|
[2] |
ROD
|
NH
|
| 18. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Lower Apron
|
| 19. |
9601394
|
[2] |
BELT,1830.00 mm L
|
NH
|
| 20. |
48653
|
[2] |
CABLE
|
NH
|
| 23. |
165549
|
[2] |
WASHER
|
NH
Washer, Fabric 1/2" Thick
|
| 24. |
86640799
|
[6] |
SPACER
|
NH
|
| 25. |
86628837
|
[6] |
SPRING,Compression, 23mm OD x 57.15mm L
|
NH
|
| 29. |
25937
|
[2] |
SPACER
|
NH
|
| 45. |
87397
|
[4] |
COTTER PIN,3/16" x 1"
|
NH
Superseded by part number: 394818
|
| 49. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 51. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 52. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 57. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 58. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 60. |
9706687
|
[2] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 66. |
87364
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
NH
|
| 67. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 68. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 72. |
87365
|
[10] |
WASHER,0.66" ID x 1.31" OD x 0.1" Thk
|
NH
|
