凯斯零件查询(BTX11) - CASE IH BALE THROWER (1/02-) (70.280.12[2]) - HYDRAULIC MOTOR MOUNT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1008 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 30. |
86635679
|
[1] |
BRACKET
|
NH
|
| 49. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 50. |
80664
|
[4] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 51. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 52. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 53. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 57. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 58. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 76. |
88472
|
[1] |
ELBOW,90º, 3/4"-14 Female x 3/4"-14 Male
|
WIN
Superseded by part number: 248994
|
| 77. |
176076
|
[1] |
FITTING
|
NH
|
| 78. |
86553260
|
[1] |
HYDRAULIC MOTOR
|
NH
Incl 81
|
| 79. |
128818
|
[1] |
UNION,3/4" - 16 ORB x 3/4" - 16 JIC
|
BHB
|
| 80. |
248986
|
[1] |
ADAPTER
|
NH
Superseded by part number: 218-5094
|
| 81. |
87042713
|
[1] |
SEAL KIT
|
WIC
Superseded by part number: 86605755
|
